SC Duplex
BNotes
SC duplex adapters can be also connected with Simplex SC plugs.
SC type attenuators (HSC-AT11K-Aπ-π) can be connected only with F type adapters.
sPlug Housing
qF Type
Part Number
HSCF-2PH2-E1(P)(31)
HSCF-2PH2-E2(P)(31)
HSCF-2PH3-B1(P)(31)
HSCF-2PH3-B2(P)(31)
7.8
25
55
CL No.
704-2109-3-31
704-2120-6-31
704-2032-0-31
704-2036-1-31
Applicable Cable Diameter
Ø2mm
Ø3mm
Boot Color
Blue
Light purple
Blue
Light purple
Polishing type
PC
AdPC
PC
AdPC
qH Type
9
25
55
Part Number
HSCH-2PH2-B1(P)(31)
HSCH-2PH2-B2(P)(31)
HSCH-2PH3-B1(P)(31)
HSCH-2PH3-B2(P)(31)
CL No.
704-2046-5-31
704-2058-4-31
704-2054-3-31
704-2050-2-31
Applicable Cable Diameter
Ø2mm
Ø3mm
Boot Color
Blue
Light purple
Blue
Light purple
Polishing type
PC
AdPC
PC
AdPC
37
