3DD5036-O-A-N-D Datasheet PDF - Jilin Sino-Microelectronics

2SD5036 -> Correct Number : 3DD5036, Marking : D5036

3DD5036 is high breakdown voltage of NPNbipolar transistor. The main process of manufacture : high voltage mesa type process, triple diffused process etc., adoption of fully plastic packge.

APPLICATIONS : Horizontal deflection output for color TV.
