Description
The HPMX-2006 upconverter/amplifier IC is designed to meet the needs of cellular and PCS telephone and wireless LAN applications.

FEATUREs
• Wide Band Operation RF Output: 800-2500 MHz IF Input: DC-900 MHz
• 2.7- 5.5 V Operation
• Mixer + Amplifier: 38 mA Mixer only: 15 mA Standby Mode: <40 µA
• Differential LO and High Impedance IF Inputs
• -8.5 dBm Mixer and +4.5␣ dBm Amplifier Output Power at 1900 MHz
• JEDEC Standard SSOP-16 Surface Mount Package

APPLICATIONs
• Cordless Handsets and Base Stations
• Wireless Data Terminals
• Cellular/PCS Handsets and Base Stations
