General Description
The HPMX-5001 Upconverter/Downconverter provides RF system designers with all of the necessary features to perform an RF-to-IF downconversion for a receive path, as well as an IF-toRF upconversion for transmit mode.

FEATUREs
• 2.7 V Single Supply Voltage
• Low Power Consumption (60␣ mA in Transmit Mode, 39 mA in Receive Mode Typical)
• 2 dBm Typical Transmit Power at 1900 MHz
• Half-Frequency VCO with Frequency Doubler
• 32/33 Dual-Modulus Prescaler
• Flexible Chip Biasing, Including Standby Mode
• TQFP-32 Surface Mount Package
• Operation to 2.5 GHz
• Use with Companion HPMX-5002 IF chip

APPLICATIONs
• DECT, UPCS and ISM Band Handsets and Basestations
