IAM-91563-TR1 Datasheet PDF - HP => Agilent Technologies

Description
Hewlett-Packard’s IAM-91563 is an economical 3V GaAs MMIC mixer used for frequency down-conversion. RF frequency coverage is from 0.8 to 6 GHz and IF coverage is from 50 to 700 MHz. Packaged in the SOT-363 package, this 4.0␣ sq. mm. package requires half the board space of a SOT-143 and only 15% the board space of an SO-8 package.

FEATUREs
• +0 dBm Input IP3 at 1.9 GHz
• Single +3V Supply
• 8.5 dB SSB Noise Figure at
   1.9 GHz
• 9.0 dB Conversion Gain at
   1.9 GHz
• Ultra-miniature Package

APPLICATIONs
• Downconverter for PCS,
   PHS, ISM, WLL, and other
   Wireless Applications
