ISL62883CEVAL2Z Datasheet PDF - Intersil

Introduction
The ISL62883CEVAL2Z evaluation board demonstrates the performance of the ISL62883 multiphase synchronous-buck PWM VCORE controller implementing Intel IMVP-6.5 protocol. The ISL62883 features Intersils Robust Ripple Regulator (R3) technology. An on-board dynamic-load generator is included for evaluating the transient-load response. It applies a 300µs pulse of approximately 25mΩ load across VO and PGND.

Contents of this document include:
• Design Criteria
• Recommended Test Equipment
• Interface Connections
• Switch Descriptions
• DIP Switch Descriptions
• Jumper Descriptions
• Test Point Descriptions
• Evaluation Board Documentation
    - Bill of materials
    - Schematic
    - Silk-screen plots
    - Board layer plots
