Description
   The K3010 series consist of two infrared emitting diodes, connected in inverse parallel, optically coupled to a phototransistor detector. They are packaged in a 4-pin DIP package and available in wide-lead spacing and SMD option.

FEATUREs
1.Current transfer ratio
   ( CTR：Min. 50% at IF=± 1mA VCE=5V )
2.High isolation voltage between input and output
   ( Viso：5000Vrms )
3.Pb free and RoHS compliant
4.MSL class 1
5.Agency Approvals
   • UL Approved (No. E169586): UL1577
   • c-UL Approved (No. E169586)
   • VDE Approved (No. 101347): DIN EN60747-5-5
   • FIMKO Approved: EN60065, EN60950, EN60335
   • SEMKO Approved: EN60065, EN60950, EN60335
   • CQC Approved: GB8898-2011, GB4943.1-2011

APPLICATIONs
• System appliances
• Limit Switches
• Sensors
• Programmable controllers applications for Low Input Photocouplers and High Vceo Photocouplers
• Telephone sets
• Telephone exchangers
• Thermostats
• Signal transmission between circuits of different potentials and impedances
