Description
M/A-COM’s MAAPSS0003 is a high power, high efficiency linear power amplifier in a miniature FQFP-N 4mm plastic package. The MAAPSS0003 includes a 2-stage amplifier and bias control network. Analog signals control output power and power-off for active and standby modes.

FEATUREs
• High Gain 2-stage HBT Amplifier
• Single Supply, 3V Operation
• 29dBm Linear Output Power
• High Efficiency
• Low Quiescent Current
• Operates in US and Korean PCS Bands
• Miniature FQFP-N 4mm Plastic Package
