DESCRIPTION
   The PLL701-11 is a Spread Spectrum Clock Generator designed for the purpose of reducing EMI in high-speed digital systems, with the selectable Center Spread modulation amplitude (see table below). The output frequency is selected by programming 4 multiplier modes. The device operates over a very wide range of input frequencies and provides 1x to 4x modulated clock outputs.

FEATURES
• Spread Spectrum Clock Generator with selectable
   multiplier ( 1x, 2x and 4x ).
• Reference input frequency: 24MHz-120MHz.
• Output frequency range: 24MHz to 240MHz.
• Selectable center spread modulation rate.
• TTL/CMOS compatible outputs.
• 3.3V Operating Voltage.
• Low short term jitter.
• Available in 8-Pin 150mil SOIC package.
