PLL701-17 Datasheet PDF - PhaseLink Corporation

DESCRIPTION
   The PLL701-17 is a Spread Spectrum Clock Generator designed for the purpose of reducing EMI in high-speed digital systems, with selectable Center Spread modulation magnitude (see table below). The multiplication factor can be selected from 4 multiplier modes. The device operates over a wide range of input frequencies and provides 1x, 2x. 2.94x and 4x modulated clock outputs.

FEATURES
• Spread Spectrum Clock Generator with selectable
   multiplier ( 1x, 2x, 2.94x and 4x ).
• Reference input frequency: 16MHz-60MHz.
• Output frequency ranges: 16MHz to 200MHz.
• Center Spread Modulation.
• TTL/CMOS compatible outputs.
• 3.3V Operating Voltage.
• Low short term jitter.
• Available in 8-Pin 150mil SOIC.
