Conformal, Single In-Line Resistor Networks (Custom)

   Wirewound or metal film performance in a space saving package.
   SIP networks available in 3 - 10 pin sizes can obtain important performance parameters in an economical, mass producible style. SIPs take up the least amount of board space and are the easiest possible configuration to hand-insert into printed circuit boards. Standard pin centers are 0.100". Passivation coatings plus a conformal coating of epoxy protect the active element from the outside environment.

FEATURES
• Lead (Pb)-free available
• Minimal PC board space
• Standard 100 mil centers
• Exceptional stability over time and temperature
   (500 ppm at + 70 °C at 2000 hours)
• Integrated construction
• Conformal coating flame resistant (UL94V-0 rating)
